Quick Details

  • Drive Wheel: 6x4
  • Capacity (Load): 31 - 40t
  • Horsepower: 251 - 350hp
  • Condition: New
  • Transmission Type: Manual
  • Emission Standard: Euro 2
  • Fuel Type: Diesel
  • Engine Capacity: > 8L
  • Gross Vehicle Weight: 11500
  • Place of Origin: Hubei, China (Mainland)
  • Brand Name: Dongfeng
  • Dimensions (L x W x H) (mm): 8200x2500x3200
  • Max. torque(N.m/rpm): 1300/900-1600
  • Max. power(Kw/rpm): 213/1900
  • Wheel base (mm): 3800+1350
  • Inner dimension (mm): 5400x2300x1500
  • Max speed(km/h): 80
  • Front/Rear tread(mm): 2040/1820
  • Payload(Kg): 33800
  • Max. gradeability(%): 30
  • G.V.W.(Kg): 45300
  • Curb weight(Kg): 11500

Packaging & Delivery

Packaging Details: nude
Delivery Detail: 25-30 days after received the deposit

Dongfeng 6x4 dumper truck for sale







Specification
Drive mode6×4
EngineModeldCi290-30
Max. power(Kw/rpm)213/1900
Max. torque(N.m/rpm)1300/900~1600
Cylinder bore ×Stroke(mm)123×156
Displacement(ml)11120
Type of FuelDiesel
Compression ratio16.4:1
CabD310-S1Single berth
Capacity3 persons
GearboxType9JS150J
Max. output torque(N.m)1500
Gear ratio9 forward &1reverse 12.36 7.35 5.20 3.77 2.76 1.95 1.38 1.00 0.733/12.93
ClutchΦ430mmdiaphragm spring clutch
Frame                           Height×Width× Thickness(mm)300×90×(8+8)
Frame width 940 (front ), Frame width 800 (rear)
No of Spring leaves 9/10
TyreSize11.00R20
Air conditionerA/C
DimensionsOverall dimension (mm)8200×2500×3200
Inner dimension (mm)5400×2300×1500
Wheel base (mm)3800+1350
Front/Rear tread(mm)2040/1820
App./Dep. angel (°)30/25
PerformanceMax. speed (km/h)80
Max. gradeability(%)30
Min. turning diameter(m)16.5
MassPayload(Kg)33,800
Curb weight(Kg)11,500
G.V.W.(Kg)45,300
